X7SPA and X7SPE Motherboard Series User's Manual
X7SPA-H/X7SPE-H/X7SPE-H-D525/X7SPA-H-D525 Only
•
6 SATA connectors for 6 devices
•
RAID support: RAID 0, 1, 5, 10 (Windows OS), RAID 0, 1, 10 (Linux OS)
•
Dual 10/100/1000 LAN (Intel 82574L)
•
Two Fast UART 16550-compatible serial ports (one back panel, one
header)
•
Eight (8) USB 2.0 ports & headers (USB1/2, USB5~10): Two ports on the
back panel, five USB headers for front panel access, and one on-board
Type A USB port.
•
Optimized for the Supermicro 1U (502, 503, 510, 512) & SC731 chassis.
•
20-pin TPM header (X7SPE-H-D525 only)
X7SPA-HF/X7SPE-HF/X7SPE-HF-D525, X7SPA-HF-D525 Only
•
All the features of the X7SPA-H/X7SPE-H/X7SPE-H-D525/X7SPA-H-D525
•
Nuvoton WPCM450 BMC (Integrated IPMI 2.0, shared with LAN1)
Other
•
Chassis Intrusion Header and Detection
•
Lead free
CD Utilities
•
BIOS flash upgrade utility, Drivers and utilities for Intel® ICH9/9R chipset
Dimensions
•
Mini ITX form factor, 6.75" x 6.75" (X7SPA Series)
•
Flex ITX form factor, 7.5" x 6.75" (X7SPE Series)
