Chapter 1: Introduction

1-19

BIOS

32 Mb AMI BIOS

®

, SPI Flash BIOS

PC Health Monitoring

Onboard voltage monitors for CPU Cores, Chipset Voltage, Memory Voltage
+1.8V, +3.3V, +5V, +/- 12V, +3.3V standby, +5V standby, VBat, HT

Tachometer monitoring

Status monitor for speed control, on/off control

Supports 3-pin fans (w/o speed control)

Low-noise fan speed control

Temperature monitor for chassis, CPU environments

CPU thermal trip support

Supero Doctor III, Watch Dog/NMI

CPU/System overheat LED, Suspend state LED

Power Configuration

ACPI/ACPM Power Management

Wake-On-Ring, Wake-On-LAN headers

Keyboard wake-up from soft off

CPU fan auto-off in sleep mode

Power on mode for AC power recovery

I/O Controllers and Ports

Built-in ICH9/9R SATA Controller

Winbond Super I/O controller 83627DHG-P

One PS/2 mouse and one PS/2 keyboard port

One back panel VGA port

X7SPA-L Only

4 SATA connectors for 4 devices

Single 10/100/1000 LAN (Intel 82574L)

Four Fast 16550-compatible UART serial ports (one on back panel, three
internal headers)

Realtek ALC888-VC2-GR HD Audio

Ten (10) USB 2.0 ports & headers (USB1~USB10): Four ports on the back
panel, five USB headers for front panel access, and one on-board Type A
USB port.

Front panel HD audio header, 18-bpp LVDS connector

Optimized for the Supermicro 1U SC512 & SC731 chassis.
