1-18
X7SPA and X7SPE Motherboard Series User's Manual
Motherboard Features
Processor
X7SPA-L
Single Integrated Intel® ATOM™ D410 processor, 1.66 GHz, 10 Watts, 512KB
L2 cache, Single Core, Dual Threads.
X7SPA-H, X7SPA-HF, X7SPE-H, X7SPE-HF
Single Integrated Dual-Core Intel® ATOM™ D510 processor, 1.66 GHz, 13
Watts, 2 x 512KB L2 cache, Dual Core, 4 Threads.
X7SPE-H-D525, X7SPE-HF-D525, X7SPA-H-D525, X7SPA-HF-D525
Single Integrated Dual-Core Intel® ATOM™ D525 processor, 1.8 GHz, 13
Watts, 2 x 512KB L2 cache, Dual Core, 4 Threads.
Memory
X7SPA-L, X7SPA-H, X7SPA-HF, X7SPE-H, X7SPE-HF
Supports up to 4GB of unbuffered 667/800 MHz Non-ECC DDR2 SO-DIMMs
in 2 sockets (1.8V, 256MB, 512MB, 1GB, 2GB)
X7SPE-H-D525, X7SPE-HF-D525, X7SPA-HF-D525, X7SPA-H-D525
Supports up to 4GB of unbuffered 800 MHz Non-ECC DDR3 SO-DIMMs in
2 sockets (1.5V, 256MB, 512MB, 1GB, 2GB)
Note: 1666 MHz and 1333 MHz memory may be used, but will operate at
800 MHz.
Chipset
X7SPA-L Only
Intel® ICH9
X7SPA & X7SPE Series
Intel® ICH9R
Integrated Graphics
X7SPA-L, X7SPA-H, X7SPE-H, X7SPE-H-D525, X7SPA-H-D525
Intel Graphics Media Accelerator GMA3150
X7SPA-HF, X7SPE-HF, X7SPE-HF-D525, X7SPA-HF-D525
Matrox G200eW Graphics Accelerator
Expansion Slot
X7SPA-L, X7SPA-H, X7SPA-HF, X7SPE-H, X7SPE-HF
One (1) PCI-E 1.1 x4 Gen1 (in x16 physical) slot
X7SPE-H-D525, X7SPE-HF-D525, X7SPA-HF-D525, X7SPA-H-D525
One (1) PCI-E 2.0 x4 Gen1 (in x16 physical) slot
