Chapter 1: Introduction

1-15

Number

Connectors

Description

1

KB/Mouse

PS/2 Keyboard/Mouse

2, 3

USB 1/2, USB 3/4

Back Panel USB Ports (USB 3/4: X7SPA-L only)

4

COM1

Back Panel Serial Port

5

VGA

Video/Graphics Connector

6

LAN1

RJ45 Connector for LAN1

7

LAN2

RJ45 Connector for LAN2 (Not available on the X7SPA-L)

8

J5

Front Panel Audio Header Connector (Not available on the X7SPE

series)

10

CD1

CD/DVD Drive Audio Input Header (Available on X7SPA-L Only)

15

JL1

Chassis Intrusion Header

18

JBAT1

Onboard Battery

19

JPCIE1

PCI-E 1.1 x4 Gen1 (in x16 physical) Slot 7 (Slot 6 on X7SPE

series)

20

USB 5/6, 7/8

Front Panel USB headers

21

JTPM

TPM Header (X7SPE-H-D525/X7SPE-HF-D525 Only)

22

USB 10

Type A on-board USB Port

23

USB 9

Front Panel USB header

25

JOH

Overheat Warning LED header

26

J8

Power Connector for Add-on devices (Note: Do NOT plug the

power supply into this socket).

27

SATA 0,1,2,3,4,5

SATA Connectors (SATA 2/3 is not available on the X7SPA-L)

29

JWF1

SATA Disk on Module (DOM) Power

30

T-SGPIO-0/1

Serial General Purpose IO headers (for SATA)

31

JF1

FP Control Panel Header

32

JD1

External Buzzer/Speaker/Power LED

Pins 1-3 (Power LED), Pins 4-7 (External Speaker)

33

JPI2C

PWR supply (I

2

C) System Management Bus

34

JPW1

ATX 24-Pin Power Connector

35

Unused

Factory Test Point

36

JSMB1

System Management Bus header

38, 37

Fans 1, 2

Fan 1: CPU Fan, Fan 2: Chassis Fan Header

39, 40, 41

COM2, COM4,

COM3

Serial Port 2, 4 and 3 Headers (COM 3/4 X7SPA-L only)

45

SPK

Onboard Speaker/Buzzer

48

J5

18-bpp LVDS LCD Monitor Port

49

J6

Inverter Connector

50

DIMM 1, DIMM 2

SO-DIMM Memory Slots

Ports and Connectors
