B&G H1000 Autopilot - Manual (Page 45)

description/installation
h1000 pilot
Page 44
furuno ad10 heading connection
DRIVE
SUPPLY
DRIVE
SUPPLY
IN OUT
- + - +
1A
C+
C-
D+
D-
SLV
AD1
0
Cut back unused wires
Furuno AD10 Compatible Display
Furuno AD10
Output Cable
