all rudder drives - heavy duty power cables
Total Cable Length
B&G Cable
Part No.
Copper Area
Cable Gauge
Up to 8m (26ft)
135-0A-128
4.0mm²
12 awg
Up to 12m (40ft)
Not available
6.0mm²
10 awg
Up to 20m (65ft)
Not available
10.0mm²
7 awg
linear drives - clutch/valve cables
Up to 9m (30ft)
135-0C-096
0.5mm²
22 awg
Up to 15m (50ft)
135-0B-096
0.5mm²
22 awg
acp unit terminal details
DRIVE
SUPPLY
DRIVE
SUPPLY
IN
OUT
- + - +
1A
BR
BL
SLV
R
BL
SLV
BL
R
SLV
C+
C-
D+
D-
SLV
R
W
BR
G
V
BL
Y
BLK
SLV
R
G
SLV
BL
R
R
BL
SLV
G
W
Y
BR
R
BLK
SLV
R
G
BL
SLV
BLK
G
R
SLV
CL
UT
CH
MO
B
ALAR
M
AD
10
O
U
TP
U
T
P
A
DDL
E
R
UDDE
R
JO
YSTI
C
K
HA
NDH
EL
D
wire colour coding and abbreviations
Wiring Colours
R Red
V
Violet
BLK Black
Y
Yellow
BL Blue
O
Orange
BR Brown
W
White
G Green
SLV Silver
(Not
Used)
