hydraulic ram drive dimensions (RAM-T0-12V)
4 off Mounting Holes
9mm Dia. at 76mm Centres
360
o
Movement
223mm
Midstroke 429mm (16.9")
Stroke Length 203mm (8.0")
73.3mm
125.6mm
76mm
66.7mm
9mm
16mm
12mm Dia. -0
+0.018mm
82mm
14mm
76mm
100mm
