97 English
DVR Management Menu
(Required user access level: ID4)
b [DVR Info] Window
This window consists of two tabs that display the information on the target DVR’s configurations and
hard disk status. Also, the window provides a command that initializes the hard disk(s).
You can work with this window as follows:
1 Choose either of the two tabs.
Select one of the two information tabs by clicking the tab index.
2 Import the information.
To import the latest information from the DVR and activate the tab, do the following:
• From the tree list, select a camera, and click the
button at the bottom of the
window.
• Alternatively, double-click a camera on the tree list, and click [Yes] on the confirmation
dialog that appears.
You can also access the [DVR Info] window by selecting the [Status] option on the context
menu of the tree list. In this case, the DVR information is automatically loaded without
clicking the [Import] button.
INFORMATION 1 tab
1
2
3
4
5
6
7
8
2
1
