English 20
Main Window Elements and Their Functions
5
Playback control buttons (ID2/3/4)
6
Sound playback panel (ID1/2/3/4)
1 Sound volume
2 Turn on/off sound output
3 Configuration of the sound output
channel
7
Search buttons
1 Navigate to the [Alarm Search] window
2 Navigate to the [Time Date Search] window
8
Save button (ID2/3/4)
9
Record/cut-off buttons
1 Start manual recording (ID3/4)
2 Stop manual recording (ID3/4)
3 Turn on or off the timer recording mode.
(ID3/4)
4 Disconnect the DVR. (ID1/2/3/4)
À
List display buttons
1 Open a playlist (play back downloaded
files) (ID2/3/4)
2 Show/hide the tree list (ID1/2/3/4)
1 Fast-reverse
playback
2 Play
3 Fast-forward
playback
4 Stop
(switch to live mode)
5 Pause
6 Slow-play
1 2 3
4 5 6
1
2 3
1
2
Opens dialog boxes for
saving/printing a still image
1 2 3 4
1 2
• The functions assigned to the control panel buttons are all available from the menu bar as well;
however, for simplicity, the procedures contained in this guide assume the use of the control
panel buttons.
• Commands available to a logged-in user are determined by the access level assigned to that
user. The text in parentheses indicates the user access level(s) required to use the function.
