User’s Manual
DVR-4TN/8TN/16TN/16TS/16TT Series
SPECO TECHNOLOGIES 01/06
28
3.6.2 Schedule Setup
The Schedule Setup is used to set the day, night, or weekend recording
schedule. Select from the Record Setup menu and press
ENTER; the following menu is displayed.
Schedule Setup
1. Day Time Start
2. Day Time End
3. Night Time Start
4. Night Time End
5. Weekend Schedule
6. Weekend Start
7. Weekend End 06:00
18:00
18:00
06:00
YES
Fri PM18:00
Mon AM 06:00
• Make appropriate changes for the start time of the Day Time and Night
Time schedule using the Direction keys.
• Press ENTER to confirm the settings or ESC to cancel.
• If you want to record over the weekend, choose to enable the
Weekend Schedule in advance and then set the Weekend Start/End time.
• Press ESC to back to previous page.
3.6.3 Preset Record Configuration
The is used to preset recording quality and frame rate for
normal record and event record. In normal circumstances, we strongly
suggest you set the item to , the default. Below tables show the
PPS and picture size under in Half-D1 mode. Please refer to
Section 5.4.3 Preset Record Configuration for more detailed information.
DVR-4TN/8TN/16TN
Half-D1 mode (NTSC: 720x240@60PPS; PAL: 720x288@50PPS)
Normal PPS Normal Quality Event PPS Event Quality
4CH
NTSC:15
PAL:12.5
8CH
NTSC:7.5
PAL:6.25
12 KB 20 KB
16CH
NTSC:3.75
PAL:3.12
15 KB
NTSC:30
PAL:25
25 KB
