Page 45

– 45 –

SM830092

12. SERVICE PROCEDURES

C. Check compressor motor magnetic contactor.

D. Check indoor unit P.C.B.

0628_X_S

• Check voltage between
terminals No.2 and No.4 at
terminal plate.

• Check P.C.B. Ass’y.

No voltage appears.

P.C.B. Ass’y is defective.

E. Check outdoor unit P.C.B. (CL2462R Type)

1036_X_S

• Check voltage between
terminals L1 and L2 at
terminal plate.

• Check P.C.B. Ass’y.

No voltage appears.

P.C.B. Ass’y is defective.

• Check coil resistance of
compressor motor magnetic
contactor. (52C)

1035_X_S
