5. PERFORMANCE CHARTS
230V / 208 V
• Low Pressure
Low pressure characteristics versus outdoor ambient temperature and indoor temperature.
(Indoor relative humidity: 50%, Indoor fan speed: High)
(2) High and Low Pressure
1 Indoor Unit: KS2462R Outdoor Unit: C2462R
• High Pressure
High pressure characteristics versus outdoor ambient temperature and indoor temperature.
(Indoor relative humidity: 50%, Indoor fan speed: High)
1065_X_S
85 (30)
80 (27)
75 (24)
70 (21)
Discharge pressure (psig)
440
460
480
360
340
380
400
420
320
300
59 68 77 86 95 104
(15) (20) (25) (30) (35) (40)
Outdoor ambient temp.
°
F (
°
C)
Indoor
temp.
°
F (
°
C)
Outdoor fan speed
Low High
1066_X_S
Indoor
temp.
° F ( ° C)
Outdoor fan speed
Low High
Suction pressure (psig)
140
130
150
160
170
120
110
59 68 77 86 95 104
(15) (20) (25) (30) (35) (40)
Outdoor ambient temp.
°
F (
°
C)
85 (30)
80 (27)
75 (24)
70 (21)
230V / 208 V
