– 12 –
SM830092
2. SPECIFICATIONS
(3) Other Component Specifications
(B) Outdoor Unit
MODEL No. CL2462R
Compressor Motor Magnetic Contactor FC - 1SUL
Coil rated AC 240 V, 60 Hz
Coil resistance (at 77
°
F)
Ω
587
±
5 %
Contact rated (Main) AC 240 V, 26 A
Contact rated (Auxiliary) AC 240 V, 3 A
Power Relay HH62S
Coil rated AC 240 V, 60 Hz
Coil resistance (at 77 ° F) k Ω 17.2
Contact rated AC 220 V, 5 A
Power Transformer ATR - I35B
Rated
Primary AC 220 V, 60 Hz
Secondary 14 V, 0.2 A
Capacity 2.8 VAC
Coil resistance (at 78
°
F )
Ω
WHT – WHT : 482.5 , BRN – BRN : 3.95
Thermal cut off temperature
°
F 266
Thermistor (Outdoor Temp. sensor) PBC - 41E - S4
Coil resistance k Ω 14 ° F : 23.7 , 50 ° F : 9.7
23
°
F : 18.8 , 68
°
F : 6.5
32 ° F : 15.0 , 86 ° F : 4.4
41 ° F : 12.1 , 104 ° F : 3.1
113
°
F : 2.6
Solenoid control valve or coil
Solenoid control valve VPV - 202DQ50
Solenoid coil VPV - MOAQ517B1
