VIEWING IMAGES ON A TV
The DP1 camera can be connected to a television or a video device using
the provided AV cable, allowing the recorded images to be viewed on the
television monitor or recorded on video recording media.
TO CONNECT THE CAMERA TO A
VIDEO DEVICE
1
Open the connector cover.
2
Connect the AV cable to the ᲶUSB / AVᲸ
terminal on the camera body.
3
Connect the yellow AV cable plug into the
video input terminal and the white plug into
the audio terminal of the TV
4
Turn on the camera and video device.
WARNING !!
x
Please do not use any video cable other than the one provided with your
Sigma DP1 camera. Using other brands may cause damage.
TIP
x
It is recommended that the camera be powered with the AC adapter
(optional) during television playback to avoid draining the battery.
x
The default mode for the video signal is NTSC. When connecting the camera
to a PAL device, the Video Mode setting in the Camera Set-up menu must
be changed. (See P.103, 104)
