Japan Tiger 7100e+ User Manual
Page 156

Fast Ethernet
7100e+
156
4
From the list of DHCP servers, click on a server for which
you want to create a scope.
6
Select [Add Preselection] form the [Scope] menu, input the [IP
address], [Unique ID] and [Client name] for the printer and
click [Add]. Click [Close] to go back to the origianl screen.
5
Select [Create] from the [Scope] menu, set [IP address pool]
and then click [OK].
Be sure to use [Add Preselection] to configure an IP
address. If you do not, you cannot use TCP/IP for
printing.
•
Input the Ethernet address of the Fast EtherNet into
[Unique ID] and a name of your choice into [Client
name].
•
The Ethernet address for the Fast EtherNet appears on
the self-diagnostics test print.
