37

3. Functional description. 3. Funktionsbeschreibung.

3. Description du fonctionnement.

3. Descripción del funcionamiento. 3. Funzionamento.

3. Beschrijving van functies

Positioning of controls

1. Light Switch Position.

2. Throttle control.

3. Brake and clutch pedal.

4. Motion Control Lever.

5. Attachment clutch switch.

6. Quick lifting/lower of the cutting unit.

7. Ignition lock.

8. Parking Brake.

9. Free-wheel control lever.

10. Cutting height setting.

11. Choke control.

Anordnung der Bedienungseinrichtungen

1. Lichtschalter.

2. Gashebel.

3. Brems- und Kupplungspedal.

4. Ein- und Ausschalten des Antriebes.

5. Ein- und Ausschalten des Mähaggregats.

6. Schnelles Heben und Senken des Mähaggregats.

7. Zündschloß.

8. Feststellbremse.

9. Ein-und Ausschalten des Freilaufes.

10. Mähhöheneinstellung.

11. Kalstartregler.

ELAPSED TIME

AMPS

60

0

60

HOURS 1/10

0 0 0 0 0 0 0 0 0 0

6

1

7

3

2

11

8

4

9

10

5
