50
English
Specifications
Amplifier section
Output Power:
HIGH: 40 W (20 W+ 20 W) at 4 Ω (10% THD)
50 W (25 W+ 25 W) at 4 Ω (10% MAX)
LOW: 40 W (20 W+ 20 W) at 4 Ω (10% THD)
50 W (25 W+ 25 W) at 4 Ω (10% MAX)
Analog input:
AUX: Sensitivity/Impedance (at 1 kHz)
400 mV/47 k
Ω (at “AUX LEVEL 1”)
200 mV/47 k Ω (at “AUX LEVEL 2”)
Digital output:
DVD OPTICAL DIGITAL OUT:
–21 dBm to –15 dBm (660 nm ±30 nm)
VIDEO OUT:
Color system:NTSC/PAL selectable
VIDEO (composite): 1 V(p-p)/75 Ω
S-VIDEO: Y (luminance) 1 V(p-p)/75 Ω
C (chrominance, burst)
0.286 V(p-p)/75 Ω
COMPONENT: (Interlace/Progressive):
(Y) 1 V(p-p)/75 Ω
(P B /P R ) 0.7 V(p-p)/75 Ω
Speaker Terminals: 4 Ω – 16 Ω
Others:
AV COMPU LINK x 2 ( φ 3.5)
Tuner section
FM tuning range: 87.5 MHz – 108.0 MHz
AM tuning range: 531 kHz – 1 710 kHz (at 9 kHz)
530 kHz – 1 710 kHz (at 10 kHz)
Disc player section
Playable disc: DVD Video/DVD Audio/CD/VCD/SVCD
CD-R/CD-RW (recorded in Audio CD/
Video CD/ Super Video CD/ MP3/ WMA/
JPEG format)
DVD-R/DVD-RW (recorded in video
format)
Dynamic range: 90 dB
Horizontal resolution: 500 lines
Wow and flutter: Immeasurable
MP3 recording format: MPEG 1/2 Audio Layer 3
Max. Bit rate:
320 kbps
Cassette deck section
Frequency response
Normal (type I): 50 Hz – 14 000 Hz
Wow and flutter: 0.15% (WRMS)
General
Power requirement: AC 110 V / AC 127 V /
AC 220 V– AC 230 V ,
(adjustable with the voltage selector),
50 Hz/60 Hz
Power consumption: 90 W (at operation)
12 W (on standby)
5.3 W (with deactivating the clock
indication)
Dimensions (approx.): 175 mm x 237 mm x 375 mm
(W/H/D)
Mass (approx.): 7.5 kg
Supplied Accessories
See page 3.
Speakers
Type: 2-Way Bass-reflex type
Speaker Systems: Woofer: 10 cm cone x 1
Tweeter: 4 cm cone x 1
Power handling capacity: HIGH: 20 W
LOW: 20 W
Impedance: HIGH: 4 Ω
LOW: 4 Ω
Frequency range: 56 Hz – 40 000 Hz
Sound pressure level: 84 dB/W•m
Dimensions (approx.): 145 mm x 236 mm x 205 mm
(W/H/D)
Mass (approx.): 2.3 kg each
Design and specifications are subject to change without
notice.
This product incorporates copyright protection technology
that is protected by method claims of certain U.S. patents
and other intellectual property rights owned by
Macrovision Corporation and other rights owners. Use of
this copyright protection technology must be authorized by
Macrovision Corporation, and is intended for home and
other limited viewing uses only unless otherwise
authorized by Macrovision Corporation.
Reverse engineering or disassembly is prohibited.
“CONSUMERS SHOULD NOTE THAT NOT ALL
HIGH DEFINITION TELEVISION SETS ARE FULLY
COMPATIBLE WITH THIS PRODUCT AND MAY
CAUSE ARTIFACTS TO BE DISPLAYED IN THE
PICTURE. IN CASE OF 525 OR 625 PROGRESSIVE
SCAN PICTURE PROBLEMS, IT IS RECOMMENDED
THAT THE USER SWITCH THE CONNECTION TO
THE ‘STANDARD DEFINITION’ OUTPUT. IF THERE
ARE QUESTIONS REGARDING OUR TV SET
COMPATIBILITY WITH THIS MODEL 525p AND
625p DVD PLAYER, PLEASE CONTACT OUR
CUSTOMER SERVICE CENTER.”
