Table of Contents

Parts identification ................................................ 2
Getting started ...................................................... 4

Before Installation .................................................................. 4
Checking the supplied accessories ....................................... 4
Putting batteries in the remote control ................................... 4
Connecting the FM and AM (MW) antennas ......................... 5
Connecting the speakers ....................................................... 6
Connecting video components .............................................. 7
Connecting the power cord .................................................. 11

Basic operations ................................................. 12

1 Turn on the power ............................................................. 12
2 Select the source to play .................................................. 12
3 Adjust the volume ............................................................. 13
Selecting the digital decode mode ....................................... 13
Adjusting the subwoofer audio position ............................... 14
Activating TV Direct ............................................................. 14
Turning off the sounds temporarily ...................................... 15
Changing the display brightness .......................................... 15
Turning off the power with the Sleep Timer ......................... 15

Basic settings ...................................................... 16

Setting the speaker information automatically

—Smart Surround Setup ............................................... 16

Basic setting items ............................................................... 18
Operation through on-screen display menus ....................... 18

Menu operation buttons ................................................... 18
Setup menu configuration ............................................... 19

Menu operating procedure ................................................... 20
Setting the items .................................................................. 21

Setting the speakers ....................................................... 21
Setting the virtual surround back speaker

—VIRTUAL SURROUND BACK ............................... 22

Selecting the main or sub channel—DUAL MONO ......... 22
Setting bass sound .......................................................... 23
Using the Midnight mode—MIDNIGHT MODE ............... 23
Setting the digital input (DIGITAL IN) terminals

—DIGITAL IN 1/2/3 ................................................... 24

Setting the Auto Function mode—AUTO MODE ............. 24
Selecting the type of the input signal

—DVD VIDEO INPUT/VCR VIDEO INPUT ............... 25

Superimposing the menus—SUPERIMPOSE ................ 25
Converting S-video signals into composite video signals

—DOWN MIX ............................................................ 25

Converting composite video signals into S-video signals

—Y/C SEPARATE ..................................................... 25

Sound adjustments ............................................. 26

Basic adjustment items ........................................................ 26
Operation through on-screen display menus ....................... 26

Menu operation buttons ................................................... 26
Setup menu configuration ............................................... 27

Menu operating procedure ................................................... 28
Adjusting the items .............................................................. 29

Adjusting speaker output level ........................................ 29
Adjusting the equalization patterns

—DIGITAL EQ 63Hz/250Hz/1kHz/4kHz/16kHz ........ 30

Adjusting the bass sounds .............................................. 30
Adjusting the sound parameters for the

Surround/DSP modes ............................................... 31

Tuner operations ................................................. 32

Tuning in to stations manually .............................................. 32
Using preset tuning .............................................................. 32
Selecting the FM reception mode ........................................ 33
Using the Radio Data System (RDS) to

receive FM stations ....................................................... 34

Searching for a program by PTY codes ............................... 35
Switching to broadcast program of your choice

temporarily .................................................................... 37

Creating realistic sound fields ........................... 38

Reproducing theatre ambience ........................................... 38
Introducing the Surround modes ......................................... 38
Introducing the DSP modes ................................................. 40
Activating the Surround/DSP modes ................................... 41

Operating other JVC products ........................... 44
Operating other manufacturers’ products ........ 46
Troubleshooting .................................................. 49
Specifications ...................................................... 50
