1
EN
7 Stereo Microphone
8 Grip Strap (Z p. 20)
9 HDMI Connector [HDMI] (Z p. 35)
: DC Connector [DC] (Z p. 18)
; Microphone Input Connector [MIC]
< Headphone Connector [ ]
= LED Light
> USB Connector [ 2
]
? Remote Sensor (Z p. 13)
@ Lens Cover/Lens
A Shoe (for external microphone, etc)
B Shoe Cover
C Lens Cover Switch [=, >] (Z p. 20)
D microSD Card Slot (Z p. 21)
E GZ-HD40 Everio Dock Connector
F Tripod Mounting Socket (Z p. 20)
G Battery Release Button [BATT.] (Z p. 18)
H Battery Pack Mount
Remote Control
Q Infrared Beam Transmitting Window
R ZOOM (T/W) Buttons
(Zoom in/out during playback.)
S Up Button
Rotate Button (counterclockwise) (Z p. 31)
T Skip Backward Button
U Left Button
V Back Button
W PLAYLIST Button (Z p. 42)
X START/STOP Button
Y SNAPSHOT Button (Z p. 23)
Z INFO Button (Z p. 39)
a Skip Forward Button
b PLAY/PAUSE Button
c Right Button
d Next Button
e Down Button
Rotate Button (clockwise) (Z p. 31)
f INDEX Button
g DISP Button
NOTE
You can move the zooming area with the up/
down/left/right button during zoom in playback
mode.
Camera
! Index Button [INDEX] (Z p. 33)/
Remaining Space Button/
Data Battery Button [ 0 / 1 ] (Z p. 24)
# Set Lever
Move to ¡ :
Reverse Skip (Z p. 30)/Up/Backlight
Compensation Button [ - ] (Z p. 27)
Move to ¢ :
Forward Skip (Z p. 30)/Down/Manual
Focus Button [FOCUS] (Z p. 26)
Move to £ :
Reverse Search (Z p. 30)/Left/Light
Button [LIGHT] (Z p. 24)
Move to ¤ :
Forward Search (Z p. 30)/Right/Program
AE Button [PROGRAM AE] (Z p. 26)
Press down:
Play/Pause (Z p. 30)
$ Menu Button [MENU]
% LCD Monitor
& Speaker
( Fan outlet
) Access Lamp [ACCESS] (Blinks when you
access files. Do not turn off the power or
remove the battery pack/AC adapter while
accessing files.)
Power/Charge Lamp [POWER/CHARGE]
(Blinks when you charge the battery.)
* Zoom Lever [W 7 , T ,
] (Z p. 24)
Speaker Volume Control [–VOL+] (Z p. 30)
+ Still Image Shooting Button [SNAPSHOT]
(Z p. 23)
, Auto/Manual Mode Button [AUTO] (Z p. 26)/
Information Button [INFO] (Z p. 39)
- Power Button (You can turn off the camera
by pressing and holding this button.)
. Direct Disc Button [DIRECT DISC]/
Focus Assist Button [FOCUS ASSIST]
(Z p. 27)
/ Fan inlet
0 Direct Backup Button [DIRECT BACK UP]/
Quick Review Button [QUICK REVIEW]
(Z p. 22, 23)
1 Delete Button [ * ]
2 Playback/Recording Mode Switching Button
[PLAY/REC] (Z p. 22, 23)
3 Audio/Video Connector [AV] (Z p. 36, 50)
4 Component Connector [COMPONENT]
(Z p. 35)
5 Mode Switch [!, #]
6 Video Recording Start/Stop Button [START/
STOP] (Z p. 22)
