You can install any transceiver supported by the PIC. For information about installing
and removing transceivers, see the PIC and Transceiver Installation Instructions.

NOTE: Do not install SONET/SDH SFPs in the Gigabit Ethernet port. The port will not recognize
the SFP.

■

Fiber-optic small form-factor pluggable transceivers (SFPs):

■

Duplex LC/PC connector (Rx and Tx)

■

Optical interface support—See Table 11 on page 52

■

Copper 1000Base-T SFPs:

■

Connector: Four-pair, Category 5 shielded twisted-pair connectivity through an RJ-45
connector

■

Pinout: MDI crossover

■

Length: 328 ft/100 m

Cables and connectors

OK LED, one tricolor:

■

Off—PIC is offline and it is safe to remove it from the router.

■

Green—PIC is operating normally.

■

Amber—PIC is initializing.

■

Red—PIC has an error or failure.

APP LED, one bicolor:

■

Off—Monitoring application is not running.

■

Green—Monitoring application is running under acceptable load.

Port LEDs, one per port:

■

Off—Port is not enabled.

■

Green—Port is online with no alarms or failures.

LEDs

Table 11: Optical Interface Support for Gigabit Ethernet IQ2 PICs with SFP

1000Base-LH

1000Base-LX

1000Base-SX

Parameter

Single-mode

Multimode

Optical interface

SFP

Transceiver type

Multivendor
agreement

IEEE 802.3—1998

Standard

9/125 SMF cable:
43.5 miles/70 km

9/125 SMF cable:
6.2 miles/10 km

62.5/125 or 50/125
MMF cable:
1804.5 ft/550 m

62.5/125 MMF cable:
656 ft/200 m

50/125 MMF cable:
1640 ft/500 m

Maximum distance

1480 through 1580
nm

1270 through 1355
nm

770 through 860 nm

Transmitter
wavelength

■

Gigabit Ethernet IQ2 PIC with SFP
