65440 / 65462 air motor piston rod and base, Piston rod end variety – Ingersoll-Rand 6544X-X User Manual
Page 8
Page 8 of 8
6544X-X (en)
PN 97999-64
65440 AND 65462 AIR MOTOR PISTON ROD AND BASE
ITEM 48 PISTON ROD END VARIETY
Figure 11
65020 Base and Bearing
Assembly (stub)
93312 Guide
Piston Rod
(see item 48, page 4)
93311 Retainer
Y6-66-C Screw (4 req’d)
93313 Plate (used on 65462 air motor)
Y14-616-C Lock
Washer (4 req’d)
93958 Plate (used on 65440 air motor)
Y325-210 “O” Ring
93310 Bushing
Figure 12
65911-2 Piston Rod
90108-1 Piston Rod
90573 Piston Rod
93964 Piston Rod
61776 Piston Rod
66628 Piston Rod
90595 Piston Rod
90082 Piston Rod
93289 Piston Rod
