Table 51. Two-port 232/ac dc (continued)
Wrap connector pin
to pin
Connector pin EIA 232 or V.24 EIA 366 or V.25 X.21
38 to 4 38 DTR P1 Not Used CTL-A P1
39 to 21 39 RATE P1 NB1 P1 CTL-B P1
40 40 CID 2 P1 CID 2 P1 CID 2 P1
41 41 CID 1 P1 CID 1 P1 CID 1 P1
42 42 CID 0 P1 CID 0 P1 CID 0 P1
43 to 31, 45 43 Not Used Not Used Not Used
44 to 14, 46 44 DTE P2 CRQ P2 Not Used
45 to 31, 43 45 RLB P2 NB4 P2 Not Used
46 to 14, 44 46 TI P2 DLO P2 Not Used
47 47 CID 3 P2 CID 3 P2 CID 3 P2
48 48 CID 2 P2 CID 2 P2 CID 2 P2
49 49 CID 1 P2 CID 1 P2 CID 1 P2
50 50 CID 0 P2 CID 0 P2 CID 0 P2
ISDN wrap connector and connector pin
Table 52. ISDN
Wrap connector pin to pin Connector pin ISDN
1 Cable ID (CID) 3 1 CID 3
2 to 3 2 FLASHER TRIG
3 to 2 3 Jumper to FLASHER DISCH
4 to 38 4 OPTO OUT/DEGLITCH IN
5 to 6, 18 5 FLASHER OUT
6 to 5, 18 6 OPTO OUT/DEGLITCH IN
7 to 8, 36 7 VCC OPTO
8 to 7, 36 8 Not Used
9 to 10 9 +XMIT TE DRIVER (+DATA IN)
10 to 9 10 +RCV TE DSHL (+DATA OUT)
11 to 15 11 RES
12 to 13, 33 12 Not Used
13 to 12, 33 13 Not Used
14 to 44, 46 14 Not Used
15 to 11 15 Not Used
16 to 29, 30 16 Not Used
17 17 SGND
18 to 5, 6 18 DEGLITCH DISCH
19 to 20 19 Not Used
20 to 19 20 Not Used
21 to 39 21 DEGLITCH BASE
