Device Formatting Log Example (As formatted information for A or B IPL):
DisplayHexadecimal Report for Resource
Serial
Resource
Name
Type
Model
Number
Name
STORAGE
6607
070
00-68753
Offset
0 1 2 3 4 5 6 7 8 9 A B C D E F
000180
-------- -------- -------- --------
000190
-------- -------- -------- ------01
0001A0
-------- -------- -------- --------
0001B0
-------- -------- -------- --------
0001C0
# errors # errors -------- --------
detected logged
-------- --------
0001D0
Device1 Device1 Device1 New Dev1
Type
Serial
UnitAddr Type
0001E0
New Dev1 IOP type IOP
Cache
Serial
& model Serial
Type/Mod
0001F0
Cache
-------- -------- --------
Serial
-------- -------- --------
000200
-------- -------- Device2 Device2
-------- -------- Type
Serial
000210
Device2 New Dev2 New Dev2 IOP type
UnitAddr Type
Serial
& model
000220
IOP
Cache
Cache
--------
Serial
Type/Mod Serial
--------
000230
-------- -------- -------- --------
-------- -------- -------- --------
000240
Device3 Device3 Device3 New Dev3
Type
Serial
UnitAddr Type
000250
New Dev3 IOP type IOP
Cache
Serial
& model Serial
Type/Mod
000260
Cache
-------- -------- --------
Serial
-------- -------- --------
Figure 52. Example Hexadecimal Report, Device Formatting Log Template
DisplayAdditional Information for Resource
Serial
Resource
Name
Type
Model
Number
Name
STORAGE
6607
070
00-68753
Device Errors detected . . . . . . . :
4
Device Errors logged . . . . . . . . :
3
Device . . . . . . . . . :
1
2
3
Unit Address . . . . : 010400FF 010300FF 010200FF
Ty pe . . . . . . . . :
6607
6607
6607
Serial Number . . . : 13068753 00071575 00259DE8
New Device Information:
Ty pe . . . . . . . . :
****
****
****
Serial Number . . . : 00000000 00000000 00000000
I/O Processor Information:
Ty pe . . . . . . . . :
6532
6532
6532
Serial Number . . . : 07050011 07050011 07050011
Cache Adaptor Card Information:
Ty pe . . . . . . . . :
4700
4700
4700
Serial Number . . . : 07069205 07069205 07069205
Figure 53. Example Hexadecimal Report, Device Formatting (As formatted information for A
or B IPL)
