Appendix G. Connector pin information
The following tables define the connector pins that are used with the N2800e thin
client.
Table 14. Monitor Connector
Pin Signal Signal Direction
1 Red Video Out
2 Green Video Out
3 Blue Video Out
4 Monitor Detect 2 In
5 Ground – - -
6 Red Video Ground - - -
7 Green Video Ground - - -
8 Blue Video Ground - - -
9 Not connected - - -
10 Ground - - -
11 Monitor Detect 0 In
12 Monitor Detect 1 / DDCSDA In / Out
13 Horizontal Sync Out
14 Vertical Sync Out
15 Monitor Detect 3 / DDCSCL In / Out
Connector shell Protective Ground - - -
Table 15. Keyboard and Mouse Connectors
Pin Signal
1 Data
2 Reserved
3 Ground
4 +5V dc
5 Clock
6 Reserved
Table 16. Parallel Connector
Pin Signal Signal Direction
1 Strobe In
2 Data 0 In
3 Data 1 In
4 Data 2 In
5 Data 3 In
6 Data 4 In
7 Data 5 In
8 Data 6 In
9 Data 7 In
10 ACKNLG Out
11 BUSY Out
12 PE Out
13 SELECT Out
14 AUTOFEEDXT In
15 ERROR Out
© Copyright IBM Corp. 2000 59
