BIOS Setup
AW8D 3-21
- SATA RAID ROM
This item allows you to use the boot ROM of on-chip Serial ATA RAID to boot up system.
On-Chip SATA
This item determines the function for on-chip Serial ATA.
[Disabled]: Disable the Serial ATA controller.
[Auto]: Allows the Serial ATA controller to be arranged by BIOS automatically.
[Combined Mode]: Parallel ATA and Serial ATA are combined together. Supports up to 4 IDE
drives.
[Enhanced Mode]: Enable both Parallel ATA and Serial ATA. Supports up to 6 IDE drives.
[SATA Only]: The SATA is operating in legacy mode.
※ This option is configurable only when the item [On-Chip SATA Mode] is set to
[IDE].
Mode
IDE
Channel
1 Master
IDE
Channel
1 Slave
IDE
Channel
2 Master
IDE
Channel
2 Slave
IDE
Channel
3 Master
IDE
Channel
3 Slave
IDE
Channel
4 Master
IDE
Channel
4 Slave
Enhanced
IDE1
Master
IDE1 Slave None None SATA1 SATA3 SATA2 SATA4
Combined
IDE1
Master
IDE1 Slave SATA2 SATA4 None None None None
SATA Only SATA1 SATA3 SATA2 SATA4 None None None None
※ The option [Enhanced Mode] does not support the Windows 98/ME operation
system.
SATA PORT Speed Settings
This item selects the mode for SATA PORT.
- PATA IDE Mode
This item determines the function mode for “IDE1”connector.
[IDE-1]: “IDE1” connector served as [Primary Master] and [Primary Slave] channel. “SATA2”
and “SATA4”connector served as [Secondary Master] and [Secondary Slave] channel. The
remaining “SATA1” and “SATA3” connectors are disabled.
[IDE-2]: “IDE1” connector served as [Secondary Master] and [Secondary Slave] channel.
“SATA1” and “SATA3” connector served as [Primary Master] and [Primary Slave] channel. The
remaining “SATA2” and “SATA4” connectors are disabled.
Refer to the following table for the relationships between IDE and SATA ports.
PATA IDE
Mode
IDE
Channel
1 Master
IDE
Channel
1 Slave
IDE
Channel
2 Master
IDE
Channel
2 Slave
IDE
Channel
3 Master
IDE
Channel
3 Slave
IDE
Channel
4 Master
IDE
Channel
4 Slave
Primary
IDE1
Master
IDE1 Slave SATA2 SATA4 None None None None
Secondary SATA1 SATA3
IDE1
Master
IDE1 Slave None None None None
※ This option is configurable only when the item [On-Chip SATA] is set to
[Combined Mode].
