FanEQ Control
Click key to enter its submenu (1 st FanEQ Group):
CPU/NB/SYS FanEQ Control
When set to [Enabled], these items control the CPU, NB, and/or SYS fan speed by the following
setting combinations.
- Reference Temperature
This item selects the reference point for taking temperature among the available options of CPU,
SYS, and PWM Temperature, but there is only one “CPU Temperature” item to choose for the
“CPU FanEQ Control”.
- Control Temperature High/Low
These items set the high and low temperature limit that you want to do the fan speed control.
- Fan PWM Duty Cycle High/Low
These items set the high and low limit of PWM duty cycle that you want to provide the fan with.
- DC Fan Voltage High/Low
These items set the high and low voltage limit that you want to provide the fan with.
※ The value of high limit must be set above the one of low limit.
3-8 AW8D
