Compressor and Mounting Hardware
All Models Except Platinum 5
Item
Number Part Number Description Note
Quantity Per
Package Assembly
1075071 Compressor Assembly - 6LX, 6LX02 1 1 1
1075071E WARR RPLMT - Compressor Assembly (6LX,
6LXO2) 1 1 1
2000894 Kit, Compressor Rebuild 1 1 A,F
Kit, Rebuild 1 1
Instruction Sheet 1 1
1157138 Kit, Compressor Complete Assembly - Thomas 1 1
Compressor with Mounting Hardware - Thomas 1 1
Kit, Compressor Restraint Bracket (Thomas) 1 1
Capacitor, 15 MFD 1 1
Tie Wrap (8" L) 2 1
1106690E WARR RPLMT - Compressor Assembly - Thomas
(5LX Plat.) 1 1
1109235-NLA Kit, Rebuild for Thomas Compressors 1 1 A,G,I
Kit, Rebuild 1 1
NLA - Instruction Sheet 1 1
1154510 Kit, Compressor Rebuild w/ Trigon Seals &
Instruction Sheet - IRC5LX/IRC5LXO2 (Thomas) 1 1 A,G
Kit, Compressor Rebuild w/ Trigon Seals -
IRC5LX/IRC5LXO2 Thomas 1 1
Instruction Sheet, Thomas Rebuild 2660-2650 1 1
2000904-NLA NLA - Kit, Compressor Rebuild 1 1 A,H
NLA - Kit, Rebuild 1 1
NLA - Instruction Sheet 1 1
1086187 Hose, Barbed, Patch Lock (1/2 x 1/4" NPT) 1 1 2
2001374 Fitting, Resonator 1 1 3 B
1108819 Fitting, Elbow (1/2" Beaded Hose x 1/4" NPT) 1 1 3 C
P0876X026 Clamp, Hose 1 1 4
1095537 Kit, Resonator Retro-Fit 1 1 5 B
Resonator 1 1
Screw, Phillips Pan Head (#10-16 x 1/2") 1 2
NLA - Tubing, Silicon (1/2 x 5") 1 1
Tube, Braided (10 x 1/2") 1 1
Spring, Extension (7/16 x 9-3/4" L) 1 1
Screw, Socket Button Head (1/4-20 x 3/8") 1 1
Bracket, Mounting 1 1
Clip, Flange 1 1
Fitting, Elbow (1/2" Beaded Hose x 1/4" NPT) 1 1
Tie Wrap (8" L) 1 1
Instruction Sheet 1 1
1085873 Resonator 1 1 5 C
2001682 Tie Wrap (8" L) 1 3 6
2002264 Tubing, Reinforced Braided (1/2 x 26") 1 1 7
1088316 Spring, Extension (7/16 x 9-3/4" L) 1 1 8
93
