Sieve Bed Assembly and Product Tank
All Models Except Platinum 5
Item
Number Part Number Description Note
Quantity Per
Package Assembly
1076916-NLA NLA - Cap, End, Vinyl, Black 1 1 15
1070050 Tie Wrap (3-29/32" L) 1 2 16
2001951-NLA NLA - Restrictor Assembly - IRC3LX 1 1 17
1078263-NLA NLA - Restrictor Assembly (IRC5LX) 1 1 17 C
1089455 Tie Wrap (15-1/4" L) 1 4 18
2002808-NLA NLA - Plate, Adaptor 1 1 B,D
2001673-NLA Kit, Pressure Gauge Tap In with Gauge 1 1 B,J
Fitting, Tee Barb (1/4") 1 1
Plug, Hose (1/4") 1 1
Clamp (1/4") 1 4
Tubing, Silicone (1/4 x 16") 1 1
NLA - Kit, Pressure Gauge 1 1
Instruction Sheet 1 1
2001671 Kit, Pressure Gauge Tap In without Gauge 1 1 B
Fitting, Tee Barb (1/4") 1 1
Plug, Hose (1/4") 1 1
Clamp (1/4") 1 4
Tubing, Silicone (1/4 x 16") 1 1
Instruction Sheet 1 1
2001674-NLA NLA - Kit, Pressure Gauge 1 1
A - Includes (2) Sieve Beds, (2) Clamps, (2) Hose Clamps and (4) Tie Wraps.
B - Not Shown.
C - Used on Serial Numbers: 99A655582, 99A655585, 99A655590, 99A655594, 99A655596, 99A65662, 99A65664,
99A65688, 99A65692, 99A65744, 99A65745, 99A65877, 99A65879, 99A65900.
D - Before 5/98.
E - After 4/98.
F - LX Models.
G - LX02 Models.
H - Includes Tubing, Tie Wraps, Barb Fitting and PE Valve.
I - Before 6/23/03.
J - Item no longer available. Please order part #2001671 and 2001674 as a replacement.
K - Item no longer available. Please order part #1114925 as a replacement.
L - Kit includes the Regulator, (4) Screws, (2) O-Rings
M - Kit includes Regulator, Adaptor, Restrictor, Screws, O-Rings, Tie Wraps, and Tubing.
NOTE:
65
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 93-38
