Compressor and Mounting Hardware
Perfecto2/PerfectoW
Item
Number Part Number Description Note
Quantity Per
Package Assembly
1162038 Kit, Compressor with Hardware - PW/PO2W 1 1 1 A,D
Compressor - P2/ PO2/PW/P02W 1 1
Screw, Hex Head Flange (1/4-20 x 7/8") 1 4 2
Bushing, Mounting 1 4 3
Fitting, Elbow (1/2" Beaded Hose x 1/4" NPT) 1 1 4
Elbow, Male Flare 1 1 5
Spring, Compression (63/64 x 1-1/4 x 1/16") 1 4 6
Capacitor, 10 MFD 1 1 7
Tie Wrap (17-1/2" L) 1 1 8
1162038E WARR RPLMT - Kit, Compressor w/ Hardware,
PW/PO2W 1 1 1 A
NLA - WARR RPLMT - Compressor,
P2/PO2/PW/PO2W 1 1
Screw, Hex Head Flange (1/4-20 x 7/8") 1 4 2
Bushing, Mounting 1 4 3
Fitting, Elbow (1/2" Beaded Hose x 1/4" NPT) 1 1 4
Elbow, Male Flare 1 1 5
Spring, Compression (63/64 x 1-1/4 x 1/16") 1 4 6
Capacitor, 10 MFD 1 1 7
Tie Wrap (17-1/2" L) 1 1 8
1143461 Screw, Hex Head Flange (1/4-20 x 7/8") 1 4 2
1143462 Bushing, Mounting 1 4 3
1108819 Fitting, Elbow (1/2" Beaded Hose x 1/4" NPT) 1 1 4
1169408-NLA NLA - Fitting, Elbow Swivel (1/4 NPT x 3/8 Tube) 1 1 5 E
1143489 Elbow, Male Flare 1 1 5
1143460 Spring, Compression (63/64 x 1-1/4 x 1/16") 1 4 6
1131250 Kit, Capacitor Replacement 10 MFD 1 1 7 B
1018239 Tie Wrap (17-1/2" L) 1 1 8
1153688 Kit, Compressor Rebuild w/ Instruction Sheet 1 1 C
Compressor Rebuild - Thomas 1 1
Instruction Sheet, Thomas Rebuild 2660-2650 1 1
A - Kit includes the Compressor and items 2 thru 8.
B - Includes 10MFD Capacitor and (2) Tie Wraps.
C - When replacing or servicing a compressor, Part Number 1131250 must also be replaced.
D - When ordering a replacement compressor, you should order 1143557 Heat Exchanger when replacing a unit
manufactured between 5/17/11 and 7/20/11.
E - No longer available, use 1143489 as its replacement.
NOTE:
30
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 93-38
