Cabinet and Base
10 Liter Models
Item
Number Part Number Description Note
Quantity Per
Package Assembly
1108803 Cabinet Cover without Tie Wraps 1 1 1 D,A
1006525 Tie Wrap (3-29/32" L) 1 1 2
1008547 Cord, Elastic 1 1 3
1115868 Kit, Cabinet Handle 1 1 C
Handle, Top, Warm Grey 1 1 4
NLA - Screw, Hex Head Tap (1/4-15 x 3/4") 1 2 5
1107412 Filter, Cabinet 1 1 6
1107400 Grid, Filter 1 1 7
1107414 Foam, Side Shroud 1 2 8
1107413 Foam, Front Shroud 1 1 9
1172003 Package, Power Cord Strap w/ Hardware 1 1 10
Strap, Hook and Loop 10 1 11
Rivet, Plastic 10 1 12
Retainer, Push On 10 1
1110766 Door, Filter Access with Foam Gasket 1 1 13
1105499 Base, Domestic 1 1 14 D
1108816 Foam, Base 1 1 15
1104151 Fitting, Hose Barb with Nut (1/8") 1 1 16
1108211 Cap, End, Dust, Green 1 1 17
1108764 Cord, Power 1 1 18
1056249 Relief, Strain 1 1 19
1110426 Caster Assembly (2") 1 4 20
2000576 Stand-Off, Twist-Lok (1/2") 1 1 21
2000360 Grommet, Plastic 1 4 22
2000508 Screw, Phillips Truss Head Self Tap (#8-32 x 5/8") 1 4 23
1056748-NLA NLA - Suppressor, Surge 1 1
A - Includes Cabinet Cover and Items 2-13.
C - After 6/28/07, the Hook and Loop Strap are no longer used on the Cabinet Cover Assembly. If Hook and Loop Strap is
needed you must order the Package, Cord Power Strap w/ Hardware Part Number 1172003.
D - Includes Base and items 14-21.
NOTE:
14
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 93-38
