Sound Box Assembly
Platinum 5 Models
Item
Number Part Number Description Note
Quantity Per
Package Assembly
2001361 Kit, Exhaust Fan Service 1 1 1
Fan, Exhaust 1 1
Mount, Cable Tie 1 4
Tie Wrap (3-29/32" L) 1 1
NLA - Screw, Phillips Hex Washer Head (#7-19 x
3/8") 1 1
Screw, Phillips Pan Head (10-24 x 3/4") 1 4
Tie Wrap (15-1/4" L) 1 1
Tie Wrap (8" L) 1 4
Instruction Sheet 1 1
1108783 Tubing, Braided (1/2 x 23") 1 1 2
1108784 Tubing, Braided (1/2 x 20-1/4") 1 1 3
2001765 Harness, Horn/Alarm 1 1 4
1108085 Manifold/Valve Assembly 1 1 5 B
2001682 Tie Wrap (8" L) 1 5 6
1110848 Tubing, Braided (1/2 x 6-3/16") 1 2 7
1085872 Muffler Assembly 1 1 8 F
2001116 Uni-Muffler 1 1 9 F
P0875X560 Boot, Terminal 1 1 10 M
1110776-NLA NLA - Capacitor Mounting Hardware 1 1 11 A
1068698 Capacitor, 15 MFD 1 1 12 H
1131250 Kit, Capacitor Replacement 10 MFD 1 1 12 D,I
P0876X026 Clamp, Hose 1 5 13
1108822 Elbow, PVC Formed (1/2 x 2-1/2 x 2-1/2") 1 1 14
1106698 Elbow, Silicon (1/2 x 3-1/2") 1 1 15
1108817 Heat Exchanger Assembly 1 1 16 J
1110780 Stand-Off, Heat Exchanger 1 1 17
1108810 Screw, Hi-Lo Six Lobe Drive (#10-16 x 5/8") 1 7 18
1108086-NLA NLA - Tubing (1/2 x 19") 1 1 19
1112561 Tube, Compressor 1 1 19
1101141 Kit, 4-Way Valve w/ Screws 1 1 20
1101141R Valve, Reconditioned 1 1 L
1101141E-NLA Kit, Valve - Warranty Replacement 1 1 L
Valve, Reconditioned 1 1
Gasket 1 1
Screw, Socket Head (M5 x .8 x 2mm) 1 4
1110852 Screw, Slotted Hex Washer Head (#10-24 x 1/2") 1 4 21
1003363-NLA Screw, Phillips Pan Head (#8-32 x 3/8") 1 1 22
1128404 Screw, Phillips Hex Washer Head (#8-32 x 3/8") 1 1 22
1106675 Coupling, Inlet Filter 1 1 23
2000812 Seal, Foam 1 2 24
P0750X030 Filter, HEPA Outlet 1 1 25 K
1110777-NLA NLA - Partition 1 1 26
