Compressor and Mounting Hardware
Perfecto2V
Item
Number Part Number Description Note
Quantity Per
Package Assembly
1165097 Kit, Compressor with Hardware - PO2V 1 1 1 A,D
Compressor - PO2V 1 1
Screw, Hex Head Flange (1/4-20 x 7/8") 1 4 2
Bushing, Mounting 1 4 3
Fitting, Elbow (1/2" Beaded Hose x 1/4" NPT) 1 1 4
Elbow, Male Flare 1 1 5
Spring, Compression (63/64 x 1-1/4 x 1/16") 1 4 6
Capacitor, 22MFD 1 1 7
Tie Wrap (17-1/2" L) 1 1 8
1143461 Screw, Hex Head Flange (1/4-20 x 7/8") 1 4 2
1143462 Bushing, Mounting 1 4 3
1108819 Fitting, Elbow (1/2" Beaded Hose x 1/4" NPT) 1 1 4
1169408-NLA NLA - Fitting, Elbow Swivel (1/4 NPT x 3/8 Tube) 1 1 5 E
1143489 Elbow, Male Flare 1 1 5
1143460 Spring, Compression (63/64 x 1-1/4 x 1/16") 1 4 6
1167620 Kit, Compressor Rebuild, PO2V 1 1 C
1165098 Kit, Capacitor Replacement, 22MFD 1 1 9 B
Capacitor, 22MFD 1 1 7
Tie Wrap (17-1/2" L) 1 1 8
A - Kit includes the Compressor and items 2-8
B - Kit includes items 7 and 8
C - Not Shown. Kit includes (2) ea. Cylinders, (2) ea. Seal Cups, (4) ea. Reed Valves, (4) ea. O-Rings, (12) ea. Head
Mounting Screws, (4) ea. Valve Flapper Screws, (4) Washers and Instruction Sheet
D - When ordering a replacement compressor, you should order 1143557 Heat Exchanger, when replacing a unit
manufactured between 5/17/11 and 7/20/11.
E - No longer available. Use 1143489 as its replacement.
NOTE:
32
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 93-38
