Page 49
Control Panel and P.C. Board
Perfecto2 - Perfecto2V - PerfectoW
Item
Number
Part Number
Description
Note
Quantity Per
Package Assembly
1143576
Control Panel Assembly - P2/PW
1
1
1
1143553
Control Panel with SensO2 Assembly - PO2/PO2W
1
1
1
1164802
Control Panel w/ SensO2 Assembly - PO2V
1
1
1
1110561
Flowmeter without Palnuts - 5 Liter
1
1
2
1180107
Connector, Barbed, Brass (1/4")
1
1
3
1143503
Horn/Alarm Assembly
1
1
4
1098707
Hour Meter Assembly with Clip
1
1
5
1143475
PCB Assembly - P2/PW
1
1
6
1143486
PCB Assembly - PO2/PO2W
1
1
6
1143486E
WARR RPLMT - PCB Assembly - PO2/PO2W
1
1
6
1164808
PCB Assembly - PO2V
1
1
6
1143499
Screw, Phillips Hex Washer Head (#8-16 x 3/8)
1
2
7
1143542
Breaker, Circuit 6 AMP
1
1
8
2001682
Tie Wrap (8" L)
1
2
9
1110473
Tubing, PVC (1/4 x 1-3/4")
1
2
10
2000460
Valve, Check
1
1
11
1143144
Tubing, PVC (1/4 x 5")
1
1
12
P0750X030
Filter, HEPA Outlet
1
1
13
2000507
Palnut (9/16-18)
1
3
14
2001134
Switch, On/Off
1
1
15
1008547
Cord, Elastic
1
1
16
1006525
Tie Wrap (3-29/32" L)
1
1
17
1095497
Decal, Invacare Logo (1.6)
1
1
18
1143545
Label, LED - P2/PW
1
1
19
1143479
Label, LED - PO2/PO2V/PO2W
1
1
19
1143469
Panel, Control
1
1
20
2001764
Jumper Wire Assembly
1
1
21
1163429
Package, Label, No Smoking,
Perfecto2/Perfecto2V/PerfectoW
20
1
22
1143501-NLA
NLA - Power Jumper Assembly
1
1
23
2000799
Adapter with Tubing for Humidifier Bottle
1
1
24
1128379
Package, Knob, Flowmeter, Silver w/ Black Swish
10
1
25
1128380
Package, Knob, Flowmeter, Black w/ Silver Swish
10
1
25
1143477
Main Harness Assembly
1
1
A,B
1143526
Wire Harness Valve Assembly
1
1
A,B
A - Not Shown.
B - Connects to the PC Board.
NOTE:
48
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 93-38
