Sound Box Assembly
PerfectoW
Item
Number Part Number Description Note
Quantity Per
Package Assembly
1131249 Filter, Inlet Sound Reduced 1 1 1
1153703 Tube, Clear (1/2 x 2-3/4") 1 1 2
1106675 Coupling, Inlet Filter 1 1 3
1143435 Resonator Assembly 1 1 4
1128404 Screw, Phillips Hex Washer Head (#8-32 x 3/8") 1 7 5
1143473 Soundbox, Horizontal 1 1 6
2001682 Tie Wrap (8" L) 1 3 7 A
1143484 Fan, Exhaust - P2/PW 1 1 8
1143574 Transformer Assembly - P2/PW 1 1 9
1143478 Transformer Assembly - PO2/PO2V/PO2W 1 1 9
1143491 Rivet, Isolator Mount 1 4 10
1143554 Muffler Assembly 1 1 11
1108810 Screw, Hi-Lo Six Lobe Drive (#10-16 x 5/8") 1 5 12
1147917 Mount, Foam Valve 4-Way 1 1 13
1154030 Foam, Soundbox - Vertical 1 1 14
1143474 Gusset, Soundbox 1 2 15
1172007-NLA NLA - Heat Exchanger Assembly 1 1 16 B
1143557 Heat Exchanger Assembly 1 1 16 C
1143582 Clamp, Hose Adjustable (3/8") 1 1 17
1153693 Foam, Resonator - Top 1 1 18
1153694 Foam, Resonator - Bottom 1 1 19
1153699 Foam, Soundbox - Ceiling 1 1 20
1153707 Tube, Resonator Inlet Preformed 1 1 21
1153692 Tube, Inlet Silencer 1 1 22
1153788 Resonator, Inlet 1 1 23
1153708 Tube, Resonator Outlet Preformed 1 1 24
1143445 Soundbox, Vertical 1 1 25
1169408-NLA NLA - Fitting, Elbow Swivel (1/4 NPT x 3/8 Tube) 1 1 26 D
1143489 Elbow, Male Flare 1 1 26
A - After 1/31/10, this number is the replacement for the numbers 1006525 and 2001694.
B - Use this part number to replace Heat Exchanger after 05/17/11. When ordering a new Heat Exchanger, you must also
order the fitting (1169408).
C - Use this part number to replace 1172007, you must also order 1143489 also.
D - No longer available. Use 1143489 as its replacement.
NOTE:
62
