Sound Box Assembly
All Models Except Platinum 5
Item
Number Part Number Description Note
Quantity Per
Package Assembly
Screw, Phillips Pan Head (#8-32 x 3/4") 1 2
Resistor Service Assembly 1 1
Tie Wrap, Banded (3-29/32" L) 1 2
Instruction Sheet 1 1
1083005-NLA NLA - Valve, 4-Way with Screen 1 1 20 D
1083005E-NLA NLA - Valve, 4-Way with Screws (Reconditioned) 1 1 20 D
1101141 Kit, 4-Way Valve w/ Screws 1 1 20 E
1101141R Valve, Reconditioned 1 1 B
1101141E-NLA Kit, Valve - Warranty Replacement 1 1 B
Valve, Reconditioned 1 1
Gasket 1 1
Screw, Socket Head (M5 x .8 x 2mm) 1 4
1095209 Tubing, Reinforced Braided (1/2x 4-1/8") 1 2 21
1095538 Kit, Muffler Retro-Fit 1 1 22 F
Muffler Assembly 1 1
Screw, Phillips Pan Head (#10-16 x 1/2") 1 2
Screw, Socket Button Head (1/4-20 x 3/8") 1 1
Bracket, Mounting 1 1
Clip, Flange 1 1
Instruction Sheet 1 1
1085872 Muffler Assembly 1 1 22 G
2001116 Uni-Muffler 1 1 23
2001765 Harness, Horn/Alarm 1 1 24
2003052 Valve, Operator Pilot 1 1 25 L
1085112 O-Ring, Pilot Valve (35/64" I.D.) 1 1
1080973 Kit, Pilot Valve Stem and Poppet Replacement 1 1 B
Pilot Valve Poppet and Stem 1 1
Instruction Sheet, Pilot Coil 1 1
2003083 Kit, Pilot Valve Poppet Replacement 1 1 H,B
2003082-NLA NLA - Instruction Sheet, Pilot Valve Poppet Kit 1 1 I,B
1080971 Kit, Pilot Coil Replacement 1 1 B
Coil, Pilot 1 1
Instruction Sheet, Pilot Coil 1 1
2000830 Guard, Cooler 1 1 B
51
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 93-38
