Intel ® 5100 MCH Chipset
Intel ® 5100 Memory Controller Hub Chipset for Communications, Embedded, and Storage Applications
TDG July 2008
16 Order Number: 318676-003US
5.1.2 Thermal Calibration and Controls
It is recommended that full and routine calibration of temperature measurement
equipment be performed before attempting to perform a temperature case
measurement of the Intel ® 5100 MCH Chipset. Intel recommends checking the meter
probe set against known standards. This should be done at 0 °C (using an ice bath or
other stable temperature source) and at an elevated temperature, around 80 °C (using
an appropriate temperature source).
Wire gauge and length also should be considered because some less expensive
measurement systems are heavily impacted by impedance. There are numerous
resources available throughout the industry to assist with implementation of proper
controls for thermal measurements.
Note: It is recommended to follow company standard procedures and wear safety items like
glasses for cutting the IHS and gloves for chemical handling.
Note: Ask your Intel field sales representative if you need assistance to groove and/or install
a thermocouple according to the reference process.
5.1.3 IHS Groove
Cut a groove in the package IHS according to the drawing given in Figure 6 .
Note: The center of the round at the end of the IHS groove should be at the center of the
package.
Table 5. Thermocouple Attach Support Equipment
Item Description Part Number
Measurement and Output
Microscope Olympus* light microscope or equivalent SZ-40
Digital multi-meter Digital multi-meter for resistance measurement Not Available
Test Fixture(s)
Micromanipulator 1
Micromanipulator set from YOU Ltd. or equivalent mechanical 3D arm with needle
(not included) to maintain T
C
bead location during the attach process
YOU-3
Miscellaneous Hardware
Locite* 498* Super
Bonder* Instant
Adhesive Thermal
Cycling Resistant
Super glue with thermal characteristics 49850
Adhesive accelerator Locite 7452 Tak Pak* accelerator for fast glue curing 18490
Kapton tape For holding thermocouple in place or equivalent Not Available
Thermocouple OMEGA*, 36 gauge, “T” type 5SRTC-TT-36-72
Calibration and Control
ice point* Cell OMEGA, stable 0 °C temperature source for calibration and offset TRCIII
hot point* Cell OMEGA, temperature source to control and understand meter slope gain CL950-A-110
Notes:
1. Three axes set consists of (1 ea. U-31CF), (1 ea. UX-6-6), (1 ea. USM6) and (1 ea. UPN-1). More information is
available at http://www.narishige.co.jp/you/english/products/set/index.htm .
