Installations – Intel I815E User Manual
Page 9
INSTALLATIONS
I815E User’s Manual
5
Installations
This section provides information on how to use the jumpers and
connectors on the I815E in order to set up a workable system. The topics
covered are:
Installing the CPU.............................................................6
Installing the Memory (DIMM) .........................................7
Setting the Jumpers...........................................................8
Connectors on I815E....................................................... 12
