I815E User’s Manual iii
Table of Contents
Introduction...............................................................1
Product Description ..........................................................1
Checklist...........................................................................2
Specifications....................................................................3
Board Dimensions.............................................................4
Installations ..............................................................5
Installing the CPU.............................................................6
Installing the Memory (DIMM) .........................................7
Setting the Jumpers...........................................................8
Connectors on I815E....................................................... 12
BIOS Setup..............................................................25
Drivers Installation.................................................47
Appendix .................................................................75
A. I/O Port Address Map....................................................... 75
B. Interrupt Request Lines (IRQ) ......................................... 76
