INSTALLATIONS
6 I815E User’s Manual
Installing the CPU
The I815E board supports a Socket 370 processor socket for Intel
Pentium III and Celeron processors.
The Socket 370 processor socket comes with a lever to secure the
processor. Raise this lever to about a 90
°
angle to allow the insertion of
the processor. Place the processor into the socket by making sure the
notch on the corner of the CPU corresponds with the notch on the inside
of the socket. Once the processor has slide into the socket, return the lever
to the lock position. Refer to the figures below.
After you have installed the processor into the socket, check if the
jumpers for the CPU type and speed are correct.
NOTE: Ensure that the CPU heat sink and the CPU top surface are in
total contact to avoid CPU overheating problem that would
cause your system to hang or be unstable.
