J16: USB and Primary RJ45 Connectors
J16 consists of the primary RJ-45 connector (top) and two stacked USB
ports. Refer to the section below for their respective pin assignments.

Pin #

Signal Name

1

Vcc

2

USB-

3

USB+

USB1

USB2

4

Ground

J17: Smart Card Reader Interface

J17 is a 14-pin header that provides interface for a Smart Card Reader.
The table below shows the pin assignments of this pin header.

Signal Name

Pin #

Pin #

Signal Name

Vcc

1

2

No connect

-SCRFET

3

4

SCRRST

SCRCLK

5

6

SCRIO

Ground

7

8

-SCRPRES



J18: +5V Standby Connector

J18 is the +5V standby 2-pin connector. Refer to the pin assignments
below.
