H a r d w a r e I n s t a l l a t i o n
D J 8 0 0 M o t h e r b o a r d
Components and Jumper Setting
ACPI LED
ACPI function allows the system to enter or resume from the Sus-
pend mode. If your system chassis does not have this button, the same
function may be performed from your OS; if it is supported.
Power On Switch
This switch connects to the system’s Power button allowing you to
power on and off the system. You can configure the system to use the
keyboard or mouse to power-on the system. You can also configure the
system to respond to power restoration after a power outage occurs.
These functions can be configured by making appropriate settings in
the Integrated Peripherals submenu (“Super IO Device” field) of the
BIOS.
Speaker Connector
This connects to the PC speaker installed in the system chassis.
Power LED Connector
This connector connects to the system’s Power LED. When the
system’s power is on, this LED will light.
2-9
