37
ENGLISH Specifications
Some types of composite
sync signals are not
supported.
Sync Signal Type
The following Sync signal types are supported :
• Separate sync (TTL level).
• Sync on green *.
• Composite sync (TTL level).
* Horizontal sync pulses must not be suppressed during the vertical sync
period.
RGB input connector BNC jack
Video input impedance (RGB) 75 ohms
Video amplification 0.7V p-p , 1.0V p-p (composite)
Input voltage (AC Adapter) 100 to 127 V rms 50/60 Hz
200 to 240 V rms 50/60 Hz
Power dissipation (max) 55 W
Power dissipation (in power-off
mode) 8 W
