IBM 4190 User Manual
Page 42
Remote Supervisor Adapter II SlimLine
Mounting bracket
Mounting bracket
Mounting bracket
retention latch
1.
Read
the
safety
information
that
begins
on
page
and
2.
Turn
off
the
server
and
peripheral
devices
and
disconnect
all
power
cords
and
external
cables
(see
then,
remove
the
cover
(see
PCI-X slot
Power cable
3.
If
the
riser-card
assembly
is
an
optional
PCI-X
riser-card
assembly,
disconnect
the
riser-card
power
cable
from
the
riser-card
assembly.
4.
Grasp
the
riser-card
assembly
at
the
front
and
rear
edges
and
lift
to
remove
it
from
the
server.
Place
the
riser-card
assembly
on
a
flat,
static-protective
surface.
5.
Put
the
protective
plastic
cover
on
the
Remote
Supervisor
Adapter
II
SlimLine.
6.
Turn
the
Remote
Supervisor
Adapter
II
SlimLine
so
that
the
keys
on
the
connector
align
correctly
with
the
connector
on
the
system
board.
7.
At
a
downward
angle,
insert
the
free
end
of
the
adapter
under
the
tab
on
the
mounting
bracket,
aligning
the
holes
in
the
adapter
with
the
posts
on
the
mounting
bracket.
Rotate
the
front
end
of
the
adapter
into
the
front
mounting
bracket,
aligning
the
holes
in
the
adapter
with
the
posts
on
the
front
mounting
bracket.
28
IBM
System
x3250
M2
Types
4190
and
4194:
User’s
Guide
