58 73D0024
KHLDV Series Gas Fireplace repLaceMent partS
SIGnature coMManD SySteM
Item Description qty. KHLDV400ntSc KHLDV400ptSc KHLDV500ntSc KHLDV500ptSc
1. Gas Valve Assembly 1 80D0001 80D0002 80D0001 80D0002
2. Pilot Assembly 1 80D0039 80D0040 80D0039 80D0040
3. Control Box 1 80D0037 80D0038 80D0037 80D0038
4. Command Center 1 80D0005 80D0005 80D0005 80D0005
5a. Tube, Rear, Venturi 1 73D349K 73D3549K 54D0564 54D0564
5b. Tube, Front, Venturi 1 73D0562K 73D0562K 43D0185 43D1085
5c. Rear Tube, Tee to Solenoid 1 73D3529K 73D3529K 73D3529K 73D3529K
5d. Rear Tube, Solenoid to Venturi 1 73D3528K 73D3528K 73D3528K 73D3528K
5e. Tube, Front, Through-wall 1 73D0146K 73D0146K 73D0146 73D0146
6. Flexhose w/Shutoff Valve 1 69D0030 69D0030 69D0030 69D0030
7a. Rear Injector 1 58D0102 58D0052 57D0679 57D0680
7b. Front Injector 1 57D0612 58D0056 56D3059 62D3005
8a. Rear Burner Assembly 1 73D3270 73D3270 73D3268 73D3268
8b. Front Burner Assembly 1 73D3269 73D3269 73D3267 73D3267
9. Venturi 1 45D0600 45D0600 45D0600 45D0600
10. Wire Valve/Control (not shown) 1 80D0010 80D0010 80D0010 80D0010
11. Wire AC Module (not shown) 1 80D0009 80D0009 80D0009 80D0009
12 Wire Command Ctr. (not shown) 1 80D0008 80D0008 80D0008 80D0008
13. Remote Transmitter (full function) 1 TSFRSC TSFRSC TSFRSC TSFRSC
14. AC Module 1 SCSACM SCSACM SCSACM SCSACM
15. Solenoid (not shown) 1 73D3007 73D3007 73D3007 73D3007
accessories
16. Forged Andiron 13" 1 FA113 FA113 FA113 FA113
17. Cast Iron 12 1 / 2 " 1 CAI121/2 CAI121/2 CAI121/2 CAI121/2
18. SCS Wall Extension Kit 1 SCSWEK SCSWEK SCSWEK SCSWEK
(15' Wire, Rough-in Box, Wall Cover)
19. Decorative Door Kit 1 KHL400ADBT KHL400ADBT KHL500ADBT KHL500ADBT
Fuel conversion Kits - Signature command System
natural Gas to Lp
KHLDV400 Kit #KHL400CKPS
KHLDV500 Kit #KHL500CKPS
Lp to natural Gas
KHLDV400 Kit #KHL400CKNS
KHLDV500 Kit #KHL500CKNS
