MQp20p STaNDBY geNeRaTOR • OpeRaTiON aND paRTS MaNual — Rev. #1 (11/28/11) — page 17

gEnEraL InfOrMatIOn

pRiNCiple OF OpeRaTiON

This generator is a brushless, self-excited, externally

voltage regulated, synchronous AC generator. The

generator is made up of six major components: main stator

(armature), main rotor (field), exciter stator (field), exciter

rotor (armature), rectifier assembly, and voltage regulator.
The generator's exciter consists of a stationary field and

a rotating armature. The stationary field (exciter stator)

is designed to be the primary source of the generator's

residual magnetism. This residual magnetism allows the

exciter rotor (armature) to produce AC voltage even when

the exciter stator (field) is not powered. This AC voltage

is rectified to DC by the rotating rectifier assembly and

fed directly to the main rotor (field). As the generator

shaft continues to rotate, the main rotor (field) induces a

voltage into the generator's main stator (armature). At rated

speed, the main stator's voltage produced by the residual

magnetism of the exciter allows the automatic voltage

regulator to function.
The regulator provides voltage to the exciter resulting in

a build-up of generator terminal voltage. This system of

using residual magnetism eliminates the need for a special

field flashing circuit in the regulator. After the generator

has established the initial residual voltage, the regulator

provides a controlled DC field voltage to the exciter stator

resulting in a controlled generator terminal voltage.

vOlTage RegulaTiON

In the standard configuration (shunt excited), the automatic

voltage regulator receives both its input power and voltage

sensing from the generator's output terminals. The regulator

automatically monitors the generator's output voltage

against an internal reference set point and provides the

necessary DC output voltage to the exciter field required

to maintain constant generator terminal voltage. The

generator's terminal voltage is changed by adjusting the

regulator's reference set point.

eNgiNe

This standby generator incorporates a Perkins 404D-22

Tier 4 diesel engine. This engine is designed to meet every

performance requirement for the generator. Refer to Table 2

for engine specifications.
In keeping with Multiquip’s policy of constantly improving

its products, the specifications quoted herein are subject

to change without prior notice.

eleCTRONiC gOveRNOR SYSTeM

The electronic governor system controls the RPMs of the

engine. When the engine demand increases or decreases,

the governor system regulates the frequency variation to

± 0.25%.
