Installation – Multiquip 20 KW Standby Generator MQP20P User Manual
Page 14
page 14 —MQp20p STaNDBY geNeRaTOR • OpeRaTiON aND paRTS MaNual — Rev. #1 (11/28/11)
InStaLLatIOn
GROUND ROD
FOR EARTH
GROUND
GROUND CABLE
GENERATOR
GROUND LUG
CONNECT TO
BUILDING
GROUND
8 FT. MINIMUM
REFERENCE
NEC 250-52(C)
NOTE: GROUND LUG
MUST BE INSTALLED BY USER
Figure 2. Typical Generator Grounding Application
