HBDV7 Series Direct Vent Gas Fireplace

56

54D8000

RePlACeMeNt PARtS

SIGNAtuRe CoMMAND SySteM

Ref. Description

qty.

HBDV300NSC7 HBDV300PSC7 HBDV400NSC7 HBDV400PSC7

1. Gas Valve Assy.

1

80D0001

80D000

80D0001

80D000

. Pilot Assembly

1

80D0006

80D0007

80D0006

80D0007

3. Control Box

1

80D0018

80D0019

80D0018

80D0019

4. Command Center

1

80D0005

80D0005

80D0005

80D0005

5. Burner Tube

1

54D609

54D609

54D6004

54D6004

6. Flexhose with Shutoff Valve

1

69D0030

69D0030

69D0030

69D0030

7. Injector

1

0H3155

0H3156

6D3004

33D5039

8a,b. Burner Assembly

1

54D5115

54D5115

54D5006

54D5006

9. Venturi

1

69D1119

69D106

69D1119

69D106

10. Wire Valve Control (not shown) 1

80D0010

80D0010

80D0010

80D0010

11. Wire

Command Ctr Control Box '

1

80D0008

80D0008

80D0008

80D0008

(not shown)

1. A/C Adapter

1

80D0041

80D0041

80D0041

80D0041

Accessories

13. Hand Held Remote Control w/ HI/LO & Timer

RMSC

14. Hand Held Remote Control w/HI/LO & Tstat

RTSC

15. Touch Screen Remote w/Opt. Light, Auxiliary, Blower Control

TSFSC

16. Touch Screen Remote Hi/Lo & Timer

TSMSC

17. Touch Screen Remote Hi/Lo & TStat

TSTSC

18. SCS Wall Mount Extension Kit (15' wire, rough-in box, wall cover) (not shown)

SCSWEK

19. SCS AC Module (Opt. Blower, Light & Aux. Control)

SCSACM

Fuel Conversion Kits - Signature Command System
Natural Gas to lP

HBDV300

Kit #HB300CKPS

HBDV400

Kit #HB400CKPS

lP to Natural Gas

HBDV300

Kit #HB300CKNS

HBDV400

Kit #HB400CKNS

*Note: TSFSC must be used with SCS A/C Module to
control blower, lights and aux.
