HBDV7 Series Direct Vent Gas Fireplace

30

54D8000

oPeRAtING INStRuCtIoNS - MIllIVolt

PILOT

OF

F

PILOT

O

N

OF

F

PILO

T

ON

PILOT

FP1937

control knob on

Figure 49 -
On Position

PILOT

OF





 P

IL

O

    ON

FP1935
control knob pilot

Figure 48 -
On/Off/RS Switch

OFF

ON

RS

lIGHtING BuRNeR

MAIN BuRNeR SWItCH
The “ON/OFF/RS” switch for the main burner can be found
behind door of the fireplace. This switch allows you to turn on
and to turn off the main burner without using the gas valve knob.
Make sure the button is in the “ON” position to light the main
burner.

Figure 48

lIGHtING tHe BuRNeR
Depress and turn the knob counterclockwise

to the “ON”

position.

Figure 49.

It will take less than four (4) seconds for the

burner to ignite.

PIlot PoSItIoN
Depress and turn knob to pilot position to keep burner off while
maintaining the pilot light. Figure 50

Depress and turn knob clockwise

to “OFF” position. Figure 51

to tuRN oFF GAS

Figure 51 -
Off Position

Figure 50 -
Pilot Position
