HBDV7 Series Direct Vent Gas Fireplace
34 54D8000
To Junction Box
In Fireplace
WHITE
BLACK WHITE
BLACK
BLACK
WHITE
GREEN
Connector
Pin To Contro l Box
{
{
Optional
Light
Optional
AUX
Blower (300w Max)
FP2103
AC fan wiring
Figure 55 -
Blower Wiring Diagram
FP103
Control Box
optional AC
Module
oPtIoNAl FAN BloWeR SySteMS
N
ote
the black and white wires on the AC box
wiring harness are marked ‘Blower’, ‘light’
and ‘Aux’. It is important to use the wires
marked ‘Blower’ or the control will not work
correctly.
W
ARNING
electrical connections should only be
performed by a qualified licensed electrician.
Main power supply must be turned off before
connecting the fan to the main electrical
power supply or performing service.
BlotSC SIGNAtuRe CoMMAND BloWeR
electrical Grounding Instructions: this
appliance is equipped with a three-prong
(grounding) plug for your protection against
shock hazard and should be plugged directly
into a properly grounded three-prong
receptacle.
W
ARNING
The BLOTSC Blower Kit requires the SCSACM A/C Mod-
ule and the TSFSC remote to install and operate this kit.
Refer to blower instructions for installation.
