MSI G52-MA00628 - Manual (Page 80)

Appendix
A-8
Testing the Connected Speakers
To ensure 4- or 6-channel audio operation works properly, you may
need to test each connected speaker to make sure every speaker work properly.
If any speaker fails to sound, then check whether the cable is inserted firmly
to the connector or replace the bad speakers with good ones.
Testing Each Speaker:
1. Click the audio icon from the window tray at the bottom of the
screen.
2. Click the Speaker Test tab.
3. The following window appears.
4. Select the speaker which you want to test by clicking on it.
Note:
6 speakers appear on the “Speaker Test” window only when
you select “6 channels mode” in the “No. of Speakers” column.
If you select “4 channels mode”, only 4 speakers appear on the
window.
Subwoofer
Front Right
Rear Right
Center
Front Left
Rear Left
